Cub 40R USA Player Series

Cub 40R USA Player Series

from 1,299.00

To select custom tolex and other options click "add to cart" button above.

Made to Order 2-4 Week Lead Time

  • 40 Watt Class A  (2 x EL34)

  • Cathode biased

  • K Master® circuit

  • Foot-switchable 12AX7 or EF86 pre-amp tubes

  • Foot-switchable boost circuit

  • 4, 8, 16 ohm selector

  • Studio grade plate reverb

  • Effects loop

Overview

The USA Player Series Cub 40R preserves the purity of the original Cub circuit while offering increased flexibility. The EL34 power section adds huge headroom, percussive lows and glassy highs to this classic circuit. This improved design offers the ability to select between a 12AX7 or EF86 pre-amp tube using the mini toggle on the faceplate or the included footswitch. This new feature offers far more gain and versatility than previous Cub models.

We also added a selectable tone stack boost in both modes to give this pure single channel amp four unique gain stages. It can achieve everything from the traditional Cub 12AX7 chime to complex EF86 gain tones that were unachievable on earlier versions of the Cub.

A two button footswitch to select the EF86 or 12AX7 pre-amp tube and engage the boost is included.

K Master®  Patent Pending

The K Master® circuit is a completely original approach to power amp management which simultaneously controls current, voltage, gain, harmonic clipping and signal amplitude at intricate variables at the turn of one knob. This groundbreaking analog circuitry can achieve any amount of gain at any desirable volume while keeping tone and touch response 100% intact. The K Master also allows the power tube section to achieve something never before possible. When turned beyond 2 o'clock on the dial it begins to push the power section into harmonic saturation independent of the where the preamp gain is set. Combine this function with the pre-amp set sparkling clean to achieve big clean tones that ooze with rich power tube harmonics.

Reverb

We discovered a unique way to make our reverb sit perfectly in the mix without ever overpowering the instrument or stealing tone from the preamp. This approach produces studio grade reverb right through your loudspeaker.

Electronics

Power: 40 Watts
Channels: 1

Tubes

Power Tubes: 2 x EL34
Pre-Amp Channel 1: 12AX7 and EF86
Tone Stack Buffer: 12AX7
Phase Inverter: 12AX7

Rectifier

Solid State

Speaker

Proprietary Bad Cat UK Celestion Speaker (8 ohms)

External Construction

Chassis: Welded Aircraft Aluminum
Head Shell: Finger-Joined Italian Poplar
Combo: Finger-Joined 11 Ply Baltic Birch
Heavy Duty Leather Handle
Powder Coated Steel Corners

Weights and Dimensions

Head:              31 lbs, 21" W x 10.5" D x 10" H
112 Combo:   48 lbs, 24" W x 10.5" D x 18.5" H

Operating Manuals & Tube Charts

USA Player Series Cub 40R Operating Manual

Configuration:
Quantity:
Add To Cart

Custom Options

When you are dropping that hard earned coin on a new amplifier, we know that you want to be making an investment that will last a lifetime. With over 9,000 different color and option combos you have full control over what you amp will look like. We believe you should be getting the amp of your dreams. Even if it is fluorescent green and tweed. Yes you can choose that. Wouldn't be our first choice, but hey. We aren't the ones buying the amp.

Take a look at the variety of tolex, grill cloth, handle and corner options. Then select whether you want a head or combo then select add to cart. Before taking you to the cart to checkout you will be able to select all of the options you want to see in your amp. If at any point you have questions in this process, please don't hesitate to reach out. We would be happy to discuss ideas and options. Oh and we love talking tone too!

Tolex

Each tolex option below is available for use on both the cabinet and valence/face plate. You can have a matching cabinet and front face plate or mix and match tolex to give your amp or cabinet a one off look.

Grillcloth & Piping Options

Handle & Corner Options


Cub 40R USA Player Series Videos
